LM358 100 Times Gain Signal Amplifier Module COM52, R38

DescriptionThe LM358 100 Times Gain Signal Amplifier Module is a ready-to-use module designed to amplify small analog signals with a gain of up to 100 times. It is based on the LM358 operational amplifier, which is a low-power, dual op-amp IC suitable for single-supply operation. Here’s a breakdown of the module’s features and details:Features:High Gain: Amplifies input signals by 100 times (adjustable with onboard potentiometer).Low Power Consumption: Operates with low power requirements.Wide Operating Voltage: Typically works within a voltage range of 3V to 12V DC.Easy Integration: Equipped with input/output pins and a potentiometer for adjusting gain.Versatile Applications: Can amplify signals from various sensors (e.g., thermocouples, microphones, and photodiodes).Specifications:Chip: LM358Power Supply Voltage: 3V–12VGain Adjustment: PotentiometerInput Signal: Analog signal (e.g., sensor outputs)Output Signal: Amplified analog signalPCB Size: Typically small (varies by module manufacturer)Pin Description:VCC: Power supply (3–12V).GND: Ground.IN: Analog signal input.OUT: Amplified signal output.Applications:Amplifying low-voltage signals from sensors.Audio signal amplification.Analog data preprocessing for ADC modules.Biomedical signal processing (e.g., ECG, EMG signals).
